Product Description
The 72V 105Ah Golf Cart Lithium Battery differs from the 100Ah version in both capacity and maximum continuous current. Its 24S1P architecture retains 105Ah through the series string, with an 87.6V maximum charging voltage. Bluetooth and RS485 are listed monitoring routes. The selected controller protocol and vehicle installation determine how those functions are implemented in the cart.
Technical Specifications
| Item | Confirmed Specification |
|---|---|
| Chemistry | LiFePO4 |
| Cell brand and format | 24 pcs EVE 3.2V 105Ah prismatic cells |
| Series configuration | 24S1P |
| Market voltage class | 72V |
| Nominal voltage | 76.8V |
| Rated capacity | 105Ah at 25 +/- 2 degrees C |
| Nominal energy | 8.064kWh, calculated from 76.8V x 105Ah |
| Maximum charge voltage | 87.6V |
| Discharge cut-off voltage | 60V |
| Maximum charge current | 105A |
| Standard discharge current | 105A |
| Maximum continuous discharge | 150A |
| Cycle-life reference | 2,000 cycles with at least 80% remaining capacity; supplied test conditions should be confirmed for the order |
| Approximate weight | 58kg |
| Communication / monitoring | Bluetooth and RS485; protocol and display/app scope require order confirmation |
Product Details
Check the 150A configuration identity
Keep the BMS and finished power connection in the approved sample specification. Verify charger compatibility with the 24S pack, and record mounting details for the approximately 58kg reference.
Production and Handling Context
Request a Configuration Review
Send cart controller limits, charger model and tray dimensions to New Journey for a 72V 105Ah Golf Cart Lithium Battery quotation.
FAQ
What should I compare before selecting 72V 105Ah Golf Cart Lithium Battery?
Start with the Chemistry, Cell brand and format, Series configuration listed for this model. Send the application limits with your inquiry so the selected configuration can be checked against them.
Can the 105Ah rating be used to select the vehicle controller?
The 105Ah figure describes capacity. This reference separately lists 105A standard discharge and 150A maximum continuous discharge. Select the controller using the approved current limit and operating conditions, rather than treating ampere-hours as amperes.
What charging voltage and current are specified for this model?
Maximum charge voltage: 87.6V; Maximum charge current: 105A. Match the charger profile, polarity and connection to the ordered assembly. A voltage-class label alone does not establish compatibility with an existing charger.
What does the listed weight tell me about installation?
Approximate weight: 58kg. Weight alone does not define the battery envelope or mounting points. Obtain the external dimensions and retention drawing for the selected build before modifying the vehicle tray. Include the terminal position and access needed to secure the battery.
