Product Description
A forklift battery may contribute to the truck’s required operating mass, making weight a functional selection criterion. The 48V 210Ah LiFePO4 Forklift Battery has a 200kg reference mass that must be compared with the truck manufacturer’s requirements. The top connection area also needs access after installation. Charge and discharge limits are defined with the truck, BMS and charger rather than inferred from 210Ah capacity.
Technical Specifications
| Product voltage class | 48V |
|---|---|
| Nominal battery configuration | 51.2V 210Ah LFP |
| Rated capacity | 210Ah |
| Nominal energy | 10.75kWh |
| Chemistry | LiFePO4 / LFP |
| Dimensions (L × W × H) | 949 × 374 × 449 mm |
| Pack weight | 200 kg |
| Housing | Metal enclosure |
| Power connection | Top-mounted connection area; final connector type and orientation are confirmed per project |
| Charge / discharge limits | Confirmed against the approved truck, BMS and charger configuration |
| Communication / interface | Confirmed according to equipment and charger requirements |
Product Details
Match the battery to the named forklift
Use the truck model, compartment drawing and charging specification to define acceptance. Verify the finished case and retention points alongside capacity and voltage records for the ordered configuration.
Production and Handling Context
Prepare a Product Enquiry
Send shift load profile, truck model and battery-compartment requirements to New Journey for a 48V 210Ah LiFePO4 Forklift Battery quotation.
FAQ
What should I compare before selecting 48V 210Ah LiFePO4 Forklift Battery?
Start with the Nominal battery configuration, Rated capacity, Nominal energy listed for this model. Send the application limits with your inquiry so the selected configuration can be checked against them.
What must the forklift drawing confirm before a sample order?
Check the 949 x 374 x 449mm enclosure against the battery compartment, the 200kg reference mass against the truck requirement, and clearance above the top connections. Current limits and communication are still project-specific; enclosure fit alone does not establish electrical compatibility.
Is a final charger setting supplied for this forklift battery?
No fixed charge-current or voltage limit is supplied in this reference. They are confirmed for the approved truck, BMS and charger combination. Provide the charger specification and truck requirements before the sample configuration is released.
Which connection details should be fixed for this battery?
Power connection: Top-mounted connection area; final connector type and orientation are confirmed per project. The selected connector must match polarity, lead routing and the permitted load of the complete assembly. Where alternatives are listed, select the exact version in the order drawing.
